Thermal Dynamics CUTMASTER Service Manual

CUTMASTER 40mm
GENERAL INFORMATION 1-2 Manual 0-5085
• Besurethereisnocombustibleorammablematerialinthe
workplace. Any material that cannot be removed must be
protected.
• Ventilateallammableorexplosivevaporsfromtheworkplace.
• Donotcutorweldoncontainersthatmayhaveheldcombus-
tibles.
• Providearewatchwhenworkinginanareawhererehazards
may exist.
• Hydrogengasmaybeformedandtrappedunderaluminum
workpieces when they are cut underwater or while using a water
table. DO NOT cut aluminum alloys underwater or on a water
table unless the hydrogen gas can be eliminated or dissipated.
Trapped hydrogen gas that is ignited will cause an explosion.
NOISE
Noise can cause permanent hearing loss. Plasma arc processes can
cause noise levels to exceed safe limits. You must protect your ears
from loud noise to prevent permanent loss of hearing.
• Toprotectyourhearingfromloudnoise,wearprotectiveear
plugs and/or ear muffs. Protect others in the workplace.
• Noiselevelsshouldbemeasuredtobesurethedecibels(sound)
do not exceed safe levels.
• Forinformationonhowtotestfornoise,seeitem1inSubsec-
tion 1.03, Publications, in this manual.
PLASMA ARC RAYS
Plasma Arc Rays can injure your eyes and burn your skin. The plasma
arc process produces very bright ultra violet and infra red light. These
arc rays will damage your eyes and burn your skin if you are not
properly protected.
• Toprotectyoureyes,alwayswearaweldinghelmetorshield.
Also always wear safety glasses with side shields, goggles or
other protective eye wear.
• Wearweldingglovesandsuitableclothingtoprotectyourskin
from the arc rays and sparks.
• Keephelmetandsafetyglassesingoodcondition.Replace
lenses when cracked, chipped or dirty.
• Protectothersintheworkareafromthearcrays.Useprotective
booths, screens or shields.
• UsetheshadeoflensassuggestedinthefollowingperANSI/
ASCZ49.1:
Minimum Protective Suggested
Arc Current Shade No. Shade No.
 LessThan300* 8 9
 300-400* 9 12
400 - 800* 10 14
* These values apply where the actual arc is clearly
seen. Experience has shown that lighter filters may
be used when the arc is hidden by the workpiece.
LEAD WARNING
This product contains chemicals, including lead, or otherwise produces
chemicals known to the State of California to cause cancer, birth defects
and other reproductive harm. Wash hands after handling. (California
Health&SafetyCode§25249.5etseq.)
1.03 Publications
Refer to the following standards or their latest revisions for more
information:
1. OSHA, SAFETY AND HEALTH STANDARDS, 29CFR 1910,
obtainablefrom theSuperintendentofDocuments,U.S.
GovernmentPrintingOfce,Washington,D.C.20402
2. ANSIStandardZ49.1,SAFETYINWELDINGANDCUTTING,
obtainable from the American Welding Society, 550 N.W.
LeJeuneRd,Miami,FL33126
3. NIOSH,SAFETYANDHEALTHINARCWELDINGANDGAS
WELDINGANDCUTTING,obtainablefromtheSuperintendent
ofDocuments,U.S.GovernmentPrintingOfce,Washington,
D.C. 20402
4. ANSIStandardZ87.1,SAFEPRACTICESFOROCCUPATION
ANDEDUCATIONALEYEANDFACEPROTECTION,obtainable
from American National Standards Institute, 1430 Broadway,
New York, NY 10018
5. ANSIStandardZ41.1,STANDARDFORMEN’SSAFETY-TOE
FOOTWEAR,obtainablefromtheAmericanNationalStandards
Institute, 1430 Broadway, New York, NY 10018
6. ANSIStandardZ49.2,FIRE PREVENTION IN THE USE OF CUT-
TING AND WELDING PROCESSES, obtainable from American
National Standards Institute, 1430 Broadway, New York, NY
10018
7. AWS Standard A6.0, WELDING AND CUTTING CONTAIN-
ERS WHICH HAVE HELD COMBUSTIBLES, obtainable from
AmericanWeldingSociety,550N.W.LeJeuneRd,Miami,FL
33126
8. NFPAStandard51,OXYGEN-FUELGAS SYSTEMSFOR
WELDING,CUTTINGANDALLIEDPROCESSES, obtainable
fromtheNationalFireProtectionAssociation,Batterymarch
Park,Quincy,MA02269
9. NFPAStandard70,NATIONALELECTRICALCODE,obtainable
fromtheNationalFireProtectionAssociation,Batterymarch
Park,Quincy,MA02269
10.NFPAStandard51B,CUTTINGANDWELDINGPROCESSES,
obtainablefromtheNationalFireProtection Association,
BatterymarchPark,Quincy,MA02269
11.CGAPamphletP-1,SAFEHANDLING OFCOMPRESSED
GASES IN CYLINDERS, obtainable from the Compressed
GasAssociation,1235JeffersonDavisHighway,Suite501,
Arlington, VA 22202
12.CSAStandardW117.2,CODEFORSAFETY INWELDING
ANDCUTTING,obtainablefromtheCanadianStandardsAs-
sociation, Standards Sales, 178 Rexdale Boulevard, Rexdale,
Ontario,CanadaM9W1R3
13.NWSAbooklet,WELDINGSAFETYBIBLIOGRAPHYobtainable
fromtheNationalWeldingSupplyAssociation,1900Arch
Street,Philadelphia,PA19103
14.AmericanWeldingSocietyStandardAWSF4.1,RECOM-
MENDEDSAFEPRACTICESFORTHEPREPARATIONFOR
WELDINGANDCUTTINGOFCONTAINERSANDPIPINGTHAT
HAVEHELDHAZARDOUSSUBSTANCES,obtainablefromthe
AmericanWeldingSociety,550N.W.LeJeuneRd,Miami,FL
33126
15.ANSIStandardZ88.2,PRACTICEFORRESPIRATORYPRO-
TECTION, obtainable from American National Standards
Institute, 1430 Broadway, New York, NY 10018
