CUTMASTER 40mm

PARTS LIST 6-8 Manual 0-5085

6.10 Replacement Parts - for Machine Torches with Unshielded Leads

Item No. Qty Description Catalog No.

 1 1 TorchHeadAssemblywithoutleads(includesitems2,3,and14)  9-8220

2 1 Large O-Ring 8-3487

3 1 Small O-Ring 8-3486

 4 1 PIPSwitchKit  9-7036

5 Unshielded Automated Leads Assemblies with ATC connectors

  1  5-foot/1.5mLeadsAssemblywithATCconnector  4-7850

  1  10-foot/3.05mLeadsAssemblywithATCconnector  4-7851

  1  25-foot/7.6mLeadsAssemblywithATCconnector  4-7852

  1  50-foot/15.2mLeadsAssemblywithATCconnector  4-7853

6 Unshielded Mechanized Leads Assemblies with ATC connectors

  1  5-foot/1.5mLeadsAssemblywithATCconnector  4-7842

  1  10-foot/3.05mLeadsAssemblywithATCconnector  4-7843

  1  25-foot/7.6mLeadsAssemblywithATCconnector  4-7844

  1  50-foot/15.2mLeadsAssemblywithATCconnector  4-7845

 7 1 11”/279mmRack  9-7041

 8 1 11”/279mmMountingTube  9-7043

9 1 End Cap Assembly 9-7044

 10 2 Body,Mounting,PinchBlock  9-4513

 11 1 Pin,Mounting,PinchBlock  9-4521

 12 1 TorchHolderSleeve  7-2896

 13 1 PIPPlungerandReturnSpringKit  9-7045

1 Pinion Assembly (Not shown) 7-2827

  1 5”/126mmPositioningTube(Notshown)  9-7042

NOTE

* Does not include Control Cable Adapter or Through - Hole Protector.
