CUTMASTER 40mm
Manual 0-5085 6-1 PARTS LIST
SECTION 6:
PARTS LISTS
6.01 Introduction
A. Parts List Breakdown
The parts list provide a breakdown of all replaceable components. The parts lists are arranged as follows:
Section "6.03 Power Supply Replacement"
Section "6.04 Major External Replacement Parts"
Section "6.05 Front Panel Replacement Parts"
Section "6.06 Left Side Replacement Parts"
Section "6.07 Right Side Replacement Parts"
Section "6.08 Options and Accessories"
Section "6.09 Replacement Parts for Hand Torch"
Section "6.10 Replacement Parts - for Machine Torches with Unshielded Leads"
Section "6.11 Replacement Shielded Machine Torch Leads Assemblies"
Section "6.12 Torch Consumable Parts (SL100 SV)"
NOTE
Parts listed without item numbers are not shown, but may be ordered by the catalog number shown.
B. Returns
If a product must be returned for service, contact your distributor. Materials returned without proper authoriza-
tion will not be accepted.
6.02 Ordering Information
Order replacement parts by catalog number and complete description of the part or assembly, as listed in the parts
list for each type item. Also include the model and serial number of the power supply. Address all inquiries to
your authorized distributor.
6.03 Power Supply Replacement
The following items are included with the replacement power supply: work cable & clamp, input power cable, gas
pressure regulator / filter, and operating manual.
Qty Description Catalog #
1 CutMaster
40mm CE Power Supply
with 380/400/415VAC, 3 phase input power cable 3-1930-3
1 CutMaster
40mm Non CE Power Supply
with 380/400/415VAC, 3 phase input power cable 3-1930-4
