CUTMASTER 40MM
Manual 0-5085 5-27 SERVICE
Signal Source/Destination
J2-1 -VOUT (-) OUTPUT VOLTAGE M-L
J2-2 /TIP VOLTS Active high when tip is installed M-L
J2-3 TIP_SEN Approx. 100VDC while cutting w/ tip OFF M-L
work, Active low in Drag Mode
J2-4 /400V_IN Active low with 400VAC primary input voltage L-M
J2-5 N/A
J2-6 CUR_SET Current demand signal. Variable 1-4VDC L-M
J2-7 /RAR Active low when in Rapid Auto Restart mode L-M
J2-8 /INRUSH Active low after inrush time expires L-M
J2-9 /W1_ON Active low to enable W1 contactor L-M
J2-10 SHDN Active low enables PWM circuit
J2-11 /TRCH_SOL Active low to enable Torch Solenoid L-M
J2-12 /SOL_ON Active low to enable Power Supply solenoid L-M
J2-13 /OK_TO_MOVE Active low to enable OK_TO_MOVE (CNC) L-M
J2-14 /FAN_ON Active low to enable fans L-M
J2-15 /LATCH_ACTIVE Active low when Latch mode is active during cut L-M
J2-16 /TRCH_SW Active low = START is active -Torch switch, CNC M-L
J2-17 /PIP Active low = PARTS IN PLACE satisfied M-L
J2-18 AC_ON Pulse signal M-L
J2-19 CSR Active high during main transfer M-L
J2-20 /TORCH_SOL_DETECTED Active low for torch with remote solenoid M-L
J2-21 /OVERTEMP Active low when over temperature M-L
J2-22 V_IN Input Voltage signal M-L
2.6VDC = 400 VAC
J2-23 +12VDC M-L
J2-24 +12VDC M-L
J2-25 GND M-L
J2-26 GND M-L
J2-27 Not Used
J2-28 Not Used
J2-29 MAIN_BD_ID Voltage level to identify Main PCB = 1.1VDC M-L
J2-30 Not Used
J2-31 Not Used
J2-32 Not Used
J2-33 Not Used
J2-34 For Factory Use M-L
J2-35 +3.3VDC M-L
J2-36 TXD M-L
J2-37 RXD L-M
J2-38 Common M-L
J2-39 D M-L
J2-40 Not Used
