CUTMASTER 40MM
Manual 0-5085 5-31 SERVICE
B. CAPACITOR PCB 2 TEST POINTS
MTH 1 CAP BANK A+
MTH 2 CAP BANK A+
MTH 4 CAP BANK A-
MTH 6 CAP BANK B+
MTH 7 CAP BANK B-
MTH 8 CAP BANK B+
PMTH 1 CAP BANK A+
PMTH 2 CAP BANK A-
PMTH 3 CAP BANK B+
PMTH 4 CAP BANK B-
80A_AC1 AC line 1
80A_AC2 AC line 2
80A/AC3 AC line 3
40A_AC1 AC line 1
40A_AC2 AC line 2
40A/AC3 AC line 3
