Thermo King SPECTRUM SL User Manual

Engine Maintenance 9-41
NOTE: Can be used on tensioner service p/n: 78-1904.
Tensioner tool cannot be used on tensioner assembly service p/n: 77-3192 (implemented in October 2016).
For SLXi units, please use a size 17mm spanner wrench.
Tensioner Tool – SL, SLX, SLXe and Spectrum Units
1. Tensioner Tool
2. Tool Fixing Bolt
3. Tensioner Base
4. Tensioner Assembly
5. Tensioner Pivot Bolt
6. Tensioner Tool Nut
7. Pawl Release Mechanism
8. Tensioner Tool Socket
1
2
3
4
5
2
7
8
5
4
1
7
6
6
