Structural Maintenance 12-29
Fan Shaft Assembly – SL and SLe
1. Compressor Side Condenser Orifice
2. Control Box Side Condenser Orifice
3. Compressor Side Condenser Blower
4. Control Box Side Condenser Blower
5. Fan Shaft
6. Compressor Side Bearing Assembly
7. Compressor Side Evaporator Orifice
8. Control Box Side Evaporator Orifice
9. Evaporator Blower
10. Seal Plate (2)
11. Control Box Side Bearing Assembly
12. Fan shaft Pulley
13. Evaporator Shaft Seal Collar
14. End Shaft Screws (2)
15. Condenser Blower Mounting Screws (4)
16. Evaporator Blower Mounting Screws (2)
17. Woodruff Key (2)
18. Square Key (2)
19. Evaporator Blower Housing
20. Condenser Seal Gauge Pin
21. Evaporator Shaft Seal Gauge
22. Dry Film Lubricant
