2
Functional Description
Divert/Inject Valve
Thermo Scientific TSQ Series Hardware Manual 17
You can also use the divert/inject valve button to divert the LC flow between the mass
spectrometer and waste when the valve is in the divert valve configuration, or switch between
load and inject modes when the valve is in the loop injector configuration.
Figure 7. Divert/inject valve
Figure 8. Divert/inject valve plumbed as a loop injector and as a divert valve
LEDs
Divert/inject valve button
Divert/inject valve
Sample loop
1
2
3
4
5
1
2
3
4
5
Plumbed as a loop injector
To
waste
From
LC pump
To
ion source
From
syringe
pump
To
waste
From
LC pump
To
ion source
Plumbed as a divert valve
Plug
(optional)
