Thermo Scientific Orbitrap Fusion Series Hardware Manual 45
5
Syringe Pump and Divert/Inject Valve
This chapter describes the external syringe pump and divert/inject valve that ship with the
Orbitrap Fusion Series mass spectrometer. For information about installing these
components, refer to the Orbitrap Fusion Series Getting Connected Guide.
Syringe Pump
The external Chemyx™ Fusion 100T syringe pump delivers sample solution from an installed
syringe, through the sample transfer line (red PEEK), and into the API source. The motorized
pusher block (Figure 31) depresses the syringe plunger at the flow rate specified in the data
system. (The default flow rate for calibration is 3 μL/min.)
You can start and stop the syringe pump from the data system; refer to the data system Help
for instructions. You can also start and stop the syringe pump by pressing the syringe pump
buttons.
Contents
• Syringe Pump
• Divert/Inject Valve
Note If you choose to provide a syringe pump other than the Fusion 100T, ensure that it
can provide a steady, continuous flow of 1–5 μL/min.
