THRUSH S2R – G10 - Page 167

THRUSH AIRCRAFT, INC – MODEL S2R-G10
AIRCRAFT MAINTENANCE MANUAL
Page 8-18 Effective: 03/26/2010
Table 8-3: G10 Engine Instrument Markings
Limits Features Meaning
OIL TEMP
(ºC)
-40
-40 to 55
55 to 110
110 to 127
127
Red Radial
Yellow Arc
Green Arc
Yellow Arc
Red Radial
Minimum
Caution Range
Normal Range
Caution Range
Maximum
OIL PRESSURE
(PSI)
40
40 to 70
70 to 120
120
Red Radial
Yellow Arc
Green Arc
Red Radial
Minimum
Caution Range
Normal Range
Maximum
FUEL PRESSURE
(PSI)
8
8 to 20
80 to 90
20 to 80
90
Red Radial
Yellow Arc
Yellow Arc
Green Arc
Red Radial
Minimum
Caution Range
Caution Range
Normal Range
Maximum
EGT (ºC)
Variable
770
Red “Bug”
Red Graphic
Maximum T.O.
Maximum Starting
TORQUE (%)
0 to 99
100
None
Red “Bug”
Normal Range
Maximum
TORQUE (PSI)
Value on torque
placard is maximum
None
Red “Bug”
Normal Range
Maximum
ENGINE SPEED
96 to 100 %
101%
103%
Green Arc
Red Radial
White Arrow
Normal Range
Maximum
Max Overspeed Ck.
AIRSPEED
66 to 123 mph cas
70 to 126 mph cas
126 to 159 mph cas
159 mph cas
White Arc
Green Arc
Yellow Arc
Red radial
Flap Range
Normal Range
Caution Range
Never Exceed
