TD80™ Level Gauging and Overfill Prevention System Product Manual
Rev. 2, August 4, 2015/ TD80 and Overfill Prevention System Troubleshooting Page 81
TPM 001
12. Finch Display shows an Error Code (E xx)
The transmitter constantly checks the system for errors. Detected errors are shown on the Finch
Display as an error code, E and a 2 digit number. This error code assists in diagnosing and
repairing the problem.
E 80 through E 84 indicate an error caused by an incorrect strapping table or internal transmitter
malfunction. For these errors, review the programming information, correct if necessary and
reprogram the transmitter. If the malfunction persists, then replace the transmitter and ensure it
is programmed correctly.
The error codes and possible solution are listed below.
E 00
Can’t Autorange (could not
measure level)
- possibly bent or damaged probe
- move the probe location to a less turbulent area
of the tank
- possibly defective transmitter
E 01
Too many samples rejected (too
much turbulence)
- move the probe to a less turbulent area of the
tank
- possibly defective transmitter
E 02
Internal transmitter error, Wrap
around on Timer1
- defective transmitter
E 04
Internal transmitter error, Timer1
count is too large
- defective transmitter
E 10
Internal transmitter error, timeout
between captures
- defective transmitter
E 20
No fiducial detected
- possibly defective transmitter
- possibly damaged or defective probe
- possible turbulence in the tank
- possible disconnection of transmitter and probe
- possible liquid or grease contamination of
transmitter to probe connection
E 40
Internal transmitter error, Watchdog
reset
- defective transmitter
E 80
Internal strapping table error, HH
alarm level set too close to Spill
alarm level
- incorrect strapping table, reprogram the
transmitter with a correct table
E 81
Internal strapping table error,
Alarms set, No strapping table
- program the transmitter with a strapping table
- possibly defective transmitter
E 82
Internal strapping table error
- reprogram the transmitter
- possibly defective transmitter
E 83
Internal strapping table error, error
detected in strapping table during
operation
- restart the transmitter, if problem persists then
reprogram the transmitter
- possibly defective transmitter
E 84
Internal strapping table error, error
detected in strapping table during
operation
- restart the transmitter, if problem persists then
reprogram the transmitter
- possibly defective transmitter
Error codes 01, 02, 04, 10, 20 and 40 can be combined if there is more than one error
code at a time, for example E 26 is E 02 + E 04 + E 20. E 80 to E 84 will not be combined
with any other error codes.
