6.3.8 WLAN Security Settings
SSID
Click the dropdown list to select which SSID to be configured
Encryption
None, WEP, WPA2, and WPA2 Mixed can be selected in the
dropdown list.
Authentication Mode
Enterprise type or Personal type to be selected.
WPA2 Cipher Suite
TKIP & AES can be selected
Pre-Shared Key Format
Passphrase & HEX can be selected
Pre-Shared Key
Password for the SSID
 WEP
802.1x Authentication
Tick to Enable.
Authentication
Select which type Authentication to be use for
this wireless interface
Key Length
64-bits For 10 hex digits or 5 ASCII & 128-bits
For 26 hex digits or 13 ASCII.
Key Format
Selected 64-bits dropdown only showed ASCII
(5 characters) & HEX (10 characters). Selected
128-Bits dropdown only showed ASCII (13
Characters) & HEX (26 Characters).
