- 36 -
IGMP Proxy Enable or disable the IGMP Proxy function.
WAN interface The WAN interface which runs IGMP Proxy function.
6.4.7 IGMP Snooping
This Page is used to enable or disable IGMP Snooping Function. IGMP snooping is the process of
listening to Internet Group Management Protocol (IGMP) network traffic. The feature allows a
network switch to listen to IGMP conversations between hosts and routers. By listening to these
conversations, the switch maintains the mapping relationships between ports and IP multicast
streams. For some ports which do not need this IP multicast streams, multicast streams are filtered.
6.4.8 MLD Proxy
This page is used to enable MLD Proxy Function. The Multicast Listener Discovery (MLD) Proxy
feature provides a mechanism for a device to generate MLD membership reports for all entries or
a user-defined subset entry on the device's upstream interface.
