- 35 -
RIP Enable or disable the RIP function of the router.
Interface The interface on which you want to enable RIP.
Receive Mode Indicate the RIP version in which information must be passed to the device,
and it can be accepted into its routing table.
Send Mode Indicate the RIP version this interface will use when it sends its route
information to the other device.
6.4.5 DLNA
This Page is used to enable DLNA service. By default this setting is disabled.
6.4.6 IGMP Proxy
This Page is used to configure IGMP Proxy. An IGMP proxy enables hosts in a unidirectional link
routing (UDLR) environment that is not directly connected to a downstream router to join a
multicast group sourced from an upstream network.
