4-3
Chapter 4 APPENDIX
[How to confirm the firmware version]
• Firmware version indication
The VX-3000's rmware version is expressed as shown in the following example.
Here, the individual numbers are denoted by (A) to (E).
Example :
• Each digit is dened by the indicator status of from (A) to (E) as shown below.
[VX-3004F]
Ver.1.23.45
(A) (B)(C) (D)(E)
(A) (B) (C) (D)
(E)
[VX-3008F]
(A) (B) (C)
(D) (E)
[VX-3016F]
(A) (B)
(C)
(D)
(E)
• The rmware version number is expressed in binary scale (0 = Unlit, 1 = Lit) by the 4 indicators of from (A)
to (E). Convert the binary number shown by the indicators to the decimal number referring to the table below.
Decimal number 0 1 2 3 4 5 6 7 8 9
Indicator status
4
3
2
1
The 4th digit in binary scale
4
•••
1
•••
The 1st digit in binary scale
2
•••
The 2nd digit in binary scale
3
•••
The 3rd digit in binary scale
The 4th digit in binary scale
4
•••
1
•••
The 1st digit in binary scale
2
•••
The 2nd digit in binary scale
3
•••
The 3rd digit in binary scale
: Unlit : Lit
[VX-3004F] [VX-3008F] [VX-3016F]
(Display example of Ver. 1.23.45)
(In the case of the vertically arranged indicators) (In the case of the horizontally arranged indicators)
