4-18
Chapter 4
APPENDIX
• Accessories
Rack mounting screw 5 x 12 ..................... 4
Removable terminal plug (6 pins) .............. 2
Removable terminal plug (4 pins) .............. 2
Removable terminal plug (10 pins) ............ 4
Removable terminal plug (12 pins) ............ 2
Removable terminal plug (2 pins) .............. 1
Power Source 20 – 33 V DC, removable terminal block (4 pins)
Current Consumption 0.09 A at 33 V DC input
0.11 A at 24 V DC input
LAN A, B Number of Connectors: 2 (LAN A, LAN B)
Network I/F: 100BASE-TX
Network Protocol: TCP, ARP, ICMP, HTTP
Connection Device:
VX-3004F, VX-3008F, VX-3016F,
NX-300, VX-3000CT,
VX-3000PM,
Switching HUB
Connector: RJ45 connector
Connection Cable: Category 5 twisted pair cable (CAT5) or greater
Maximum Cable Distance: 100 m (328.08 ft)
Indicators POWER (green) ... 1, RUN (green) ... 1, LINK/ACT (green) ... 2,
SIGNAL (green) ... 8, FAULT (yellow) ... 1, STATUS (green/yellow) ... 9,
SELECT (green) ... 9
Volume Control 8 channels
Operation Function key ... 9, Reset key ... 1, IP address setting switch ... 1
Operating Temperature 0 to 40 °C (32 to 104 °F)
Operating Humidity 90% RH or less (no condensation)
Finish Panel: Surface-treated steel plate, black, 30 % glossy, paint
Volume control section cover: ABS resin, gray smoke
Dimensions 482 (w) x 44 (h) x 315.2 (d) mm (18.98" x 1.73" x 12.41")
Weight 3 kg (6.61 lb)
Note: The design and specications are subject to change without notice for improvement.
• Accessories
Rack mounting screw 5 x 12 ..................... 4
Removable terminal plug (4 pins) .............. 1
2.9. VX-3000CT Control Panel
