4-22
Chapter 4
APPENDIX
2.13. RM-210F Remote Microphone Extension
Power Source Supplied from the optional RM-300X
AC Power Consumption 2.4 W (including power supply loss of the Emergency power panel)
0.4 W (standby, including power supply loss of the Emergency power panel)
Current Consumption 80 mA or less (increase in power input at the optional RM-300X)
Operation Function key ... 10
Indicator Status indicator ... 10, Selection indicator ... 10
Operating Temperature 0 to 40 °C (32 to 104 °F)
Operating Humidity 35 to 80% RH (no condensation)
Finish ABS resin, black, semi-gloss
Dimensions 110 (w) x 76.5 (h) x 215 (d) mm (4.33" x 3.01" x 8.46")
Weight 350 g (0.77 lb)
Applicable unit Remote microphone: RM-300X
Note: The design and specications are subject to change without notice for improvement.
• Accessories
Connection cable (8 pins, 8 cm or 3.15") ... 1
Joint bracket A ........................................... 2
Joint bracket B ........................................... 1
Screw for joint bracket ............................. 12
• Optional product
Wall mounting bracket: WB-RM200
2.14. RM-200RJ Terminal Unit
Applied Voltage 40 V or less
Withstand Current 1 A
DC Voltage Monitoring
Section
Monitor terminals: Terminal No. 7 (+) and Terminal No. 8 (–),
Extinguish voltage: 14 V or less, Lighting voltage: 21 V or more,
Indicator ON/OFF switchable
Connector RJ45 connector x 1
Terminal Block M3 screw terminal (10P), Barrier spacing: 6.62 mm (0.26")
Operating Temperature 0 to 40°C (32 to 104 °F)
Operating Humidity 35 to 80% RH (no condensation)
Finish Surface-treated steel plate, black, paint
Dimensions 84 (w) x 116 (h) x 25.7 (d) mm (3.31" x 4.57" x 1.01")
Weight 250 g (0.55 lb)
Note: The design and specifications are subject to change without notice for improvement.
