Chapter 3 INSTALLATION AND SETTING PROCEDURES (HARDWARE)
8.9. Sharing Standby Amplifier
Up to 8 VX-3000F units can share a single standby amplier installed in any one of them.
The standby amplier must have the rated power output equal to or larger than the maximum output of the
power ampliers which share the standby amplier.
Connect the standby amplier output connector of the VX-3000F with the built-in standby amplier to the next
VX-3000F's standby amplier input connector.
Similarly, make standby amplier output/input connections for other units one after another.
VX-3000F (With standby amplifier installed)
VX-3000F (With no standby amplifier installed)
VX-3000F (With no standby amplifier installed)
Max. 8 pcs
