2-10
Chapter 2 NOMENCLATURE AND FUNCTIONS
[Left Side]
8
6. Fuse
Use a blade fuse described below depending on
the power amplier's rated output.
VX-015DA : 10 A
VX-030DA : 20 A
VX-050DA : 30 A
7. DC power input terminal
Connect an optional DC power supply unit to this
terminal. (See the Instruction Manual attached to
the VX-3000DS or the VX-3150DS.)
[Rear]
6 7
8. Output voltage selection switch
Used to select power amplier's rated output voltage.
