Chapter 3 INSTALLATION AND SETTING PROCEDURES (HARDWARE)
Step 3. Replace the RM-300X's upper case.
Note
Note the types of screws when replacing the upper case (See Step 1.)
[Plug for connection to the RM-300X's external input terminal]
Connect the sound source's signal line to the ring and its shield line to the sleeve of the stereo mini plug.
Sleeve: Ground
TipRing: Signal line
[Stereo mini plug]
