3-48
Chapter 3 INSTALLATION AND SETTING PROCEDURES (HARDWARE)
Step 3. Using the extension cable supplied with the RM-210F, connect the RM-300X's side EXTENSION
connector to the RM-210F's side EXTENSION connector.
Step 4. Hook the bottom surface of the RM-210F onto the WB-RM200.
RM-300X
RM-210F
4
3
2
1
Extension cable
(supplied with the RM-210F)
Wall mounting bracket
WB-RM200 (option)
