Topcon DS Series User Manual

194
32.APPENDIX
Print and use targets here to check if the built-in camera is aligned correctly.
 "24.6 Camera"

• Print this page in color and in the same magnification.
32.1 Targets for Camera Check
Target for positioning 5 m from the instrument (radius: 2.63 mm)
Target for positioning 10 m from the instrument (radius: 5.25 mm)
Target for positioning 20 m from the instrument (radius: 10.50 mm)
