84
15. DISTANCE MEASUREMENT
3. Press [OFF] to finish signal checking.
Press {ESC} or tap the cross in the top-right
corner to return to the previous screen.
• When is displayed persistently, but “” is not, contact your local dealer.
• If no key operations are performed for two minutes, the display automatically returns to the previous
screen.
An angle can be measured at the same time as distance.
• The search range can be set.
"11.1 Auto Pointing Settings"
Caution
• The laser beam is emitted during Auto Pointing and Auto Tracking.
PROCEDURE
1. Face the instrument in the direction of the target
Use the sighting collimator to aim the instrument
and telescope toward the target.
"10. STARTING UP EXTERNAL LINK AND
SETTINGS"
2. Start measurement.
Press [MEAS] in the first page of Observation
mode to start measurement.
15.2 Distance and Angle Measurement
To Next Page
