6-12
6 SPECIAL MODE (Menu Mode)
2) Area Calculation from Measured Data
When 3 or more points are set, the area
surrounded by the points is calculated and the
result will be shown.
*1) To set specify point, press the {F1} (PT#) key.
*2) To show the list of the coordinate data in the file, press the {F2} (LIST) key.
Operating procedure Operation Display
1 After pressing the {MENU} key, press the {F4}
(P
↓
) key to get the menu on page 2/4.
{MENU}
{F4}
2 Press the {F2} key.
{F2}
3 Press the {F4} (P
↓
) key to get the PROGRAMS
menu on page 2/2.
{F4}
4 Press the {F1} (AREA) key.
{F1}
5 Press the {F2} (MEASUREMENT) key.
{F2}
6 Press the {F1} or {F2} key to select using GRID
FACTOR.
[Example:F2 : DON’T USE]
{F2}
7 Collimate a prism and press the {F1} (MEAS) key.
Measuring starts. *1)
Collimate P
{F1}
8 Collimate next point and press the {F1} (MEAS)
key.
Collimate
{F1}
AREA 0021
123.456 m.sq
NEXT# :DATA-22
PT# LIST UNIT NEXT
MENU 2/4
F1:MEMORY MGR.
F2:PROGRAMS
F3:GRID FACTOR P
↓
PROGRAMS 1/2
F1:REM
F2:MLM
F3:Z COORD. P
↓
PROGRAMS 2/2
F1:AREA
F2:POINT TO LINE
F3:ROAD P
↓
AREA
F1:FILE DATA
F2:MEASUREMENT
AREA
F1:USE G.F.
F2:DON’T USE
AREA 0000
m.sq
MEAS ––– UNIT NP/P
N*[n] <<< m
E: m
Z: m
>Measuring...
AREA 0001
m.sq
MEAS ––– UNIT NP/P
