Configuring the Receiver
P/N 7010-0736
3-33
11. For RTK surveys, click the Ports tab and set the following port
parameters for the serial port (Table 3-10), then click Apply
(Figure 3-27 on page 3-34).
For post-processed surveys, keep the default values
for these parameters.
Table 3-10. Receiver Parameters for the Ports Tab
Parameter Base Receiver Rover Receiver
Input n/a (Leave the default.) Select the same differential
correction format selected for
the Base.
Output Select the type and format of
differential corrections.
Select “None”.
Period (sec) Enter the interval at which the
receiver transmits differential
corrections.
n/a (Leave the default.)
Baud rate Select a baud rate to use for transmitting differential messages
from the receiver board to the modem module
The baud rate must match the modem’s serial port speed.
RTS/CTS Select to enable handshaking.
