SETTING FUNCTIONS ON SETUP SCREEN
SETTING FUNCTIONS ON SETUP SCREEN
OPERATING THE SETUP SCREEN
Various functions can be set on the SETUP screen.
PREPARATONS FOR SETTING
1 Make sure that the power cable is connected.
For connection, refer to "CONNECTING POWER CABLE" on page 18.
2 Turn ON the switch.
3 Tap the button on the control panel.
The SETUP screen is displayed.
