43
OPTIONAL OPERATIONS
OUTPUT USING RS-232C
This instrument can output data to a PC, etc. via the RS-232C interface.
1 Connect the interface cable to RS-232C OUT.
Refer to "CONNECTING EXTERNAL I/O TERMINALS" on page 19.
2 Set up of data communication settings.
For details, refer to "DATA COMMUNICATION (COMM)" on page 52.
3 Perform measurements.
4 Tap the button of the control panel.
When output is completed, "RS-232C SUCCESS" is displayed on the screen.
INPUT USING USB
This instrument can input ID numbers from a barcode reader, etc. via the USB.
1 Check the connection of USB IN.
For connection, refer to "CONNECTING EXTERNAL I/O TERMINALS" on page 19.
2 Input ID numbers from the external device.
The inputted ID numbers are displayed on the screen.
OUTPUT USING LAN
This instrument can output data to a PC, etc. via the LAN interface.
1 Connect the network cable to LAN OUT.
For connection, refer to "CONNECTING EXTERNAL I/O TERMINALS" on page 19.
2 Set up of LAN connection settings.
For details, refer to "LAN CONNECTION (LAN)" on page 53.
3 Perform measurements.
4 Tap the button of the control panel.
When output is completed, "LAN SUCCESS" is displayed on the screen.
NOTE
For explanation of messages during communication refer to the
"MESSAGE LIST" on page 58.
