TS-1 Sensor Orientation
P/N 7010-0697
2-3
Mounting each tilt sensor within +/- 20° of the pivot
centerline is a good practice. Though not necessary
for system performance, squaring the sensors to
each part of the machine makes for a cleaner
looking installation.
All tilt sensor orientation is determined when the
sensor is horizontal (zero degrees). The orientation
of each tilt sensor is entered in 3DMC.
