Verifying Aux Antenna Height
P/N 7010-0697
4-17
Verifying Aux Antenna Height
This value is not critical to measuring elevation, so verifying is not
required.
Figure 4-12. Aux Antenna Height
Verifying Boom Pivot Height
The height of the boom pivot simply allows 3DMC to create a more
accurate representation of the machine in the software’s graphics.
This measurement does not affect elevation accuracy, so verification
is not necessary.
Figure 4-13. Machine Body Size in 3DMC Graphics
