Chapter 5
5-1
LS-B10W Laser
Receiver Setup
The LS-B10W Laser Receiver adds a laser height reference to the
X62/X63 system. The LS-B10W is calibrated for its location on the
stick of the excavator.
LS-B10W Mounting
The LS-B10W laser receiver and bracket must be mounted on the left
side of the stick. The following section describes bracket mounting,
cable routing, and LS-B10W laser receiver mounting.
1. Before installing the LS-B10W bracket, you must assemble the
bracket kit. Refer to the LS-B10W indexing bracket assembly
instructions (p/n: 7030-1370) for instructions on assembling the
LS-B10W bracket.
2. After assembling the bracket, clean the painted surface of the
machine’s stick in the area where the bracket will be mounted.
NOTICE
A mark on the laser receiver is used to determine its
position on the stick. Orientation is selected in the
Laser Receiver (LSB10W) Calibration screen in
3DMC.
NOTICE
The cut out cross on the LS-B10W mount is used to
determine the laser receiver’s position on the stick.
Orientation is calibrated in the laser receiver
calibration screen in 3DMC.
