P/N 7010-0697
Chapter 2
2-1
TS-1 Sensor
Installation
Each TS-1 sensor contains a 3-axis 360° sensor element which must
be configured depending on the mounting position. The TS-1 tilt
sensors can be mounted in many orientations as long as they are
parallel to the axis being measured (Figure 2-1). Locate surfaces that
protect the sensor from physical damage and are convenient for cable
routing. When the position of the sensor is at zero degrees
(horizontal), make a note of the direction of the arrow marker on the
sensor name plate. This direction is needed during calibration. The
calibration process uses 3DMC to enter direction, orientation, and
other sensor variables.
When mounting the tilt sensors, begin with the
bucket to help simplify cable routing.
