Introduction
X63/X62 Installation and Calibration Manual
1-6
Figure 1-6. Basic Cable Connections for X62
TS-1 TILT SENSORS
BODY BOOM STICK BUCKET
LS-B10W
LASER RECEIVER
AND BRACKET
POWER
+ -
SENSOR
TERMINATOR
