Full System Test
X63/X62 Installation and Calibration Manual
6-4
Testing Machine Body Sensor
for Accuracy
Testing the sensor on the Body requires comparing the hub position
with the machine tilted at a cross slope (Figure 6-1 on page 6-5).
1. Position the machine on a cross slope at approximately 5%.
2. Place the center of the bucket on a hub and record the position.
3. Rotate the machine 90 degrees and place the center of the bucket
on the same hub.
4. Record the new position. Then subtract the two positions from
each other.
The difference between positions should be within +/- 0.2Ft.
NEZ
Machine on Cross Slope
Position 1
Position 2
Differences
