P/N 7010-0697
Chapter 3
3-1
Machine Calibration
Before calibrating TS-1 sensors, note the following:
When the system is first powered on, it may take
several minutes for the GX-60 to discover (detect)
each sensor.
Check sensor’s serial numbers before installing.
The last two digits of the serial number determine
the sensor CAN address, and must be unique to
each machine.
For example, sensor serial number 0302 and 0402
will have the same CAN address (“02”), causing
communication errors.
Also, serial numbers ending with 00 or 01 may
cause communication conflicts.
The best practice is to perform the machine
calibrations as ordered in this manual. Performing
the calibrations out of order will not affect system
performance. The exception to this is when using a
dog-bone sensor. You must calibrate the stick
sensor before calibrating the dog-bone sensor.
