Measuring Machine Lengths
P/N 7010-0697
3-3
Boom Length
Stick Length
Bucket Width and
Length (repeated for
each bucket)
Notice: Select one
bucket and calibrate
the machine. When
the system is known
to be working
correctly with the
bucket sensor, add
additional buckets.
Table 3-1. Machine Measurements (Continued)
Measurements To
Take
Screen Shot
