Verdin Carrier Board Design Guide
Preliminary – Subject to Change
Toradex AG l Ebenaustrasse 10 l 6048 Horw l Switzerland l +41 41 500 48 00 l www.toradex.com l info@toradex.com
Carrier Board Design Guide
This document is a guideline for developing a carrier board that conforms to the
specifications for the Verdin Computer Module
Initial Release: Preliminary Version
Correct position of standoff holes in carrier board land pattern drawing (Figure 92)
Remove additional notches from the drawings of the module
Correction of CTRL_SLEEP_MOCI# signal type from open drain to CMOS
Correction of standoff hole position in Figure 3
Section 2.6: add information to DSI display adapters
Replace front picture
Section 2.5.2.2: Change HDMI ESD protection IC in reference schematic
Add section 3.5 Backfeeding
Section 2.2.2.3: Update figure 10
Section 2.3.2.2: Update figure 15
Section 2.5.2.1: Update figure 28
Section 2.7.2: Update figure 36
