ATTACHMENTS
10-27TX 413 Service Manual
Rev. 001
Fig 097 CLR DSC-0300
Fig 096 CLR DSC-0299
3. Use a large slotted screw driver to prevent the
trencher shaft from spinning and remove the bearing
locknut with a spanner wrench, p/n 999-9999 (Fig.
096 and Fig. 097).
4. Remove the bearing lockwasher from the trencher
shaft (Fig. 098).
Fig 098 CLR DSC-0301
5. Remove the tongued washer from the trencher shaft
(Fig. 099).
Fig 099 CLR DSC-0302
