2. PRINTER SETUP ENGLISH VERSION EO1-33094
2.6 Printer Setting
E2-26
2.6.6 Automatic Calibration
The Auto Calibration menu allows you to select whether or not to
enable automatic calibration at power on time. When automatic
calibration is activated, the printer feeds the media for about 160
mm each time the power is turned on or the print head is open
then closed to detect the print start position.
(1) AUTO CALIB
• OFF Disabled.
• ON TRANS. Enabled. (Transmissive sensor)
• ON REFLECT Enabled. (Reflective sensor)
• ON ALL Enabled. (Transmissive & Reflective
sensors)
• ON TRANS.+Bfeed same as “ON TRANS” setting
• ON REFLECT+Bfeed same as “ON REFLECT” setting
• ON ALL+Bfeed same as “ON ALL” setting
NOTES:
1. When AUTO CALIB is enabled, an automatic calibration is
performed at an open/close of the print head and at a power on
time.
2. After the automatic calibration is performed, the media length,
effective print length, sensor type and whether the ribbon is used
or not, obtained through the calibration, will take effect until next
calibration is performed or the printer power is turned off.
(Settings specified by commands are ignored.)
3. This function is available only when the media pitch is 10.0 mm to
150.0 mm.
4. When the printer cannot detect the second black mark/gap, it will
continue to feed the media for up to 500.0mm. If a black mark/gap
is still not detected, the printer will stop, resulting in a paper jam.
5. During an automatic calibration, the printer also feeds the ribbon.
Even if the ribbon is not loaded, this will not result in an error.
However, the print condition will be automatically changed to “No
ribbon” after the calibration ends.
6. When the cutter is installed and a previous issue was performed in
cut issue mode, the media is cut and ejected after the automatic
calibration is completed.
7. When a label end occurs during an automatic calibration, the
printer stops, resulting in an error. Loading new media and
closing the print head can clear the error and resume the
automatic calibration.
8. Since the optional ribbon saving module is not available for the B-
X4T2, Setting + Bfeed will have no effect and the setting will revert
to without BFeed.
9. The feed speed during automatic calibration is 3 ips.
10. Do not open the print head during automatic calibration. The
subsequent printer operation is not guaranteed. If you open the
print head, turn off the power and back to on.
USER SYSTEM MODE
<4>LAN/WLAN
<5>BASIC
<6>Z-MODE
<7>AUTO CALIB
NOTE:
• Since the head-up function is
not provided to the B-EX4T2
and B-EX6T2, the setting and
the printer behavior will be
automatically changed to
“ON TRANS”,”ON
REFLECT”,”ON ALL” even
if “+Bfeed” is selected for
these models.
To Next Page
