1.5 Appearance
1.5.1 Dimensions
1.5.2 Front View
1.5.3 Rear View
The names of the parts or units introduced in this section are used
in the following chapters.
278
(1
0
.
9
)
460 (18.1)
Dimensions in mm (inches)
310
(12.2)
Top Cover
Media Outlet
Supply Window
LCD Message Display
Operation Panel
Reserved for Serial or
WLAN Interface
LAN Interface
AC Power Inlet
Reserved for Expansion I/O
interface
Re served for Parallel Interface
Power Switch
USB Interface
Reserved for USB Host
Interface
