2. PRINTER SETUP ENGLISH VERSION EO1-33094
2.6 Printer Setting
E2-27
2.6.7 Dump Mode Setting
In Dump Mode, the data in the receive buffer is printed. The data
is expressed in hexadecimal values. This operation allows
verification of the programming commands or the debug of the
program.
(1) BUFFER
Select the receive buffer to dump.
• RS-232C RS-232C receive buffer
• CENTRONICS Centronics receive buffer
• LAN Network I/F receive buffer
• BASIC1 BASIC Interpreter:
I/F → Interpreter buffer
• BASIC2 BASIC Interpreter:
Interpreter buffer → I/F
• USB USB receive buffer
• RFID RFID receive buffer
(2) DUMP LIST
This parameter is to choose the output destination.
• USB MEMORY Saves in the USB memory. → c
• PRINT Prints out → d
c When USB MEMORY is selected:
A file is automatically created in the USB memory and named in
the following format based on the printer model and saved date.
/ATA0/DUMP/B-EX4T1_DUMP_1007291030.BIN
(e.g. B-EX4T Type1, 10:30, July 29, 2010)
d When PRINT is selected:
Choose a printing method.
• ON DEMAND Prints 166 lines of data (approx. 50 cm), then
stops. Subsequent data is printed when the
[ENTER] key is pressed.
• ALL Prints all data in the receive buffer.
USER SYSTEM MODE
<5>BASIC
<6>Z-MODE
<7>AUTO CALIB
<8>DUMP MODE
NOTE
:
1. If a file with the same name
already exists in the USB
memory, it will be
overwritten.
2. Selecting “RS-232C” or
“CENTRONICS” without
the optional board installed
causes a 0-KB file to be
output.
3. If an error occurs while
using the USB memory, the
error message is displayed.
For details, refer to Section
2.6.12 Copying Data
to/from USB Memory.
