Toshiba B-EX4T2 SERIES User Manual

2. PRINTER SETUP ENGLISH VERSION EO1-33094
2.7 Installing the Printer Drivers
E2-54
2.7.8 Installation under Windows XP/Server2003 (USB with Plug & Play enabled)
(1) Turn on the PC.
Note: Log on as a user with administrative privilege.
(2) Turn on the printer, and connect it to the PC with a USB cable.
(3) “USB DEVICE” is detected, and the “USB Print Support” is automatically installed.
(4) The device will automatically be detected.
(5) When “Found New Hardware Wizard” is
displayed, select “Install from a list or specific
location [Advanced]” and click the [Next]
button.
(6) Select the “Search for the best driver in these
locations”. Check the “Include this location in
the search” checkbox, and click the [Browse]
button.
Specify the folder (C:\TEC_DRV) created in
Section 2.7.4, and click the [Next] button.
(7) When the screen on the right appears, click
the [Continue Anyway] button.

Toshiba B-EX4T2 SERIES Specifications

General

Print Method	Thermal transfer
Resolution	203 dpi
Print Width	104 mm
Interfaces	USB
Optional Interfaces	Wireless LAN
Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, ITF, Codabar, MSI
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	25 - 85% RH (Non-condensing)
