Toshiba B-EX4T2 SERIES - Fine Adjustment

2. PRINTER SETUP ENGLISH VERSION EO1-33094
2.9 Position and Print Tone Fine Adjustment
E2-62
2.9.1 Fine Adjustment (Cont.)
(1) FEED ADJ.
Print start position is shifted by fine adjusting the feed amount.
• Example of Print Start Position Fine Adjustment
When setting +3.0 mm
Compared with “+0.0mm” position, the print start
position is shifted forward.
When setting +0.0 mm
When setting –3.0 mm
Compared with “+0.0mm” position, the print start
position is shifted backward.
One label
Print Start Position
Print Start Position
3
mm
3mm
Feed Direction
Feed Direction
Print Start Position
One label
Feed Direction
One label
50.0mm
-50.0mm
49.9mm
-49.9mm
NOTE:
Do not set the fine adjustment value which is larger than the media
pitch. When the set value exceeds the media pitch, the printer
operation is not guaranteed.
