Toshiba Satellite A660 Series Maintenance Manual

3 Tests and Diagnostics
Satellite A660/A665 Series Maintenance Manual
2
3.1 The Diagnostic Test
This chapter explains how to use the Test & Diagnostic program to test the functions of the (Base
on PEQAA 10R/10RG T&D version 1.0) hardware modules. The program consists of a series of
tests that run automatically when the Diagnostics Program items are selected and executed.
NOTES: To start the diagnostics, follow these steps
1. Check all cables for loose connections.
2. Exit this program when you are at Main Menu.
The TEST & DIAGNOSTIC PROGRAM contains the following functional tests:
 CONFIG CHECK TEST
 AUDIO SOUND TEST
 FAN ON/OFF TEST
 MAIN BATTERY CHARGE TEST
 FDD TEST
 MEMORY CHECK
 KEYBOARD TEST
 MOUSE(PAD) TEST
 LCD PIXELS MODE TEST
 MAGNETIC SWITCH TEST
 LAN TEST
 RTC TEST
 BUTTON TEST
 1
st
HDD TEST
 Read DMI TEST
 Write DMI TEST
 G SENDOR TEST
 TP TYPE R/W TEST
 EE-PROM Setting
 TOSHIBA LOGO SET
 DYNABOOK LOGO SET
 LED TEST
You will need the following equipment to perform some of the Diagnostic test programs.
 The diagnostics USB memory
 The diagnostics CD disk
 A formatted working diskette for the floppy disk drive test (Floppy Disk Drive Test)
 A LAN loopback

Toshiba Satellite A660 Series Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	Wi-Fi 802.11b/g/n
HDMI	Yes
Battery	6-cell Lithium-ion
Processor	Intel Core i5
RAM	4GB or 8GB DDR3
Storage	Up to 640GB HDD
Graphics	NVIDIA GeForce GT 330M
Operating System	Windows 7 Home Premium or Professional
Webcam	Yes, with built-in microphone
Audio	Stereo speakers, Dolby Advanced Audio
LAN	10/100 Ethernet
Card Reader	Multi-Card Reader
USB Ports	3 x USB 2.0
Ports	Microphone input, Headphone output
