Toshiba Satellite A660 Series Maintenance Manual

2 Troubleshooting Procedures
Satellite A660/A665 Series Maintenance Manual
14
2.4 Display Troubleshooting
Perform external display check
(Procedure 1)
START
Does the external
display function ok?
Perform diagnostic check
(Procedure 2)
No
Was a display
problem detected?
Perform connector and
replacement check
(Procedure 3)
Replace system board
END
Yes
Yes
No
Display is not
faulty. Continue
troubleshooting-
refer to Figure 2-1
Figure 2-3 Display troubleshooting process
This section describes how to determine if the computer’s display is functioning properly.
The process is outlined in Figure 2-3. Start with Procedure 1 and continue with the other
procedures as instructed.

Toshiba Satellite A660 Series Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	Wi-Fi 802.11b/g/n
HDMI	Yes
Battery	6-cell Lithium-ion
Processor	Intel Core i5
RAM	4GB or 8GB DDR3
Storage	Up to 640GB HDD
Graphics	NVIDIA GeForce GT 330M
Operating System	Windows 7 Home Premium or Professional
Webcam	Yes, with built-in microphone
Audio	Stereo speakers, Dolby Advanced Audio
LAN	10/100 Ethernet
Card Reader	Multi-Card Reader
USB Ports	3 x USB 2.0
Ports	Microphone input, Headphone output
