Toshiba Satellite A660 Series Maintenance Manual

4.7 ODD Module (Tray-load) 4 Replacement Procedures
Satellite A660/A665/A660D Maintenance Manual 4-23
4.7 ODD Module (Tray-load)
Removing the ODD Module (Tray-load)
NOTE: The installation and removal procedures are the same for all the modules that can be
installed in the ODD bay. See the appropriate sections for the disassembly procedures of
specific modules.
Remove the ODD module according to the following procedures and Figure 4.14.
1. Turn the laptop upside down.
2. Remove one M2.5x8 screw.
3. Pull the ODD module in the direction of the arrow as indicated in Figure 4.14.
Figure 4.14 Removing the ODD module (Tray-load)
CAUTION: Handle the ODD module carefully. It can become hot during operation.
M2.5x8*1

Toshiba Satellite A660 Series Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	Wi-Fi 802.11b/g/n
HDMI	Yes
Battery	6-cell Lithium-ion
Processor	Intel Core i5
RAM	4GB or 8GB DDR3
Storage	Up to 640GB HDD
Graphics	NVIDIA GeForce GT 330M
Operating System	Windows 7 Home Premium or Professional
Webcam	Yes, with built-in microphone
Audio	Stereo speakers, Dolby Advanced Audio
LAN	10/100 Ethernet
Card Reader	Multi-Card Reader
USB Ports	3 x USB 2.0
Ports	Microphone input, Headphone output
