4 Replacement Procedures 4.24 LCD Panel
Satellite A660/A665/A660D Maintenance Manual 4-58
4. Remove the LCD panel.
Installing the LCD Panel
Install the LCD panel according to the following procedures.
1. Connect the LVDS cable to the back of the LCD panel.
2. Seat the LCD panel in the correct position.
3. Connect the camera cable to the camera.
4. Secure the LCD panel with the four M2.5x5 screws according to the number sequence
sealed on the hinges.
