4.20 Power Membrane 4 Replacement Procedures
Satellite A660/A665/A660D Maintenance Manual 4-49
4.20 Power Membrane
Removing the Power Membrane
Remove the power membrane according to the following procedures and Figure 4.38.
1. Peel off and remove the power membrane, taking care not to damage or tear it.
Figure 4.38 Removing the power membrane
Installing the Power Membrane
Install the power membrane according to the following procedures.
1. Seat the power membrane in the correct place and adhere it to the lower logic assembly.
NOTE: Where possible reuse the power membrane. If the power membrane is faulty or is
compromised during removal install a new power membrane.
