Toshiba Satellite A660 Series Maintenance Manual

4.19 CPU 4 Replacement Procedures
Satellite A660/A665/A660D Maintenance Manual 4-47
4.19 CPU
Removing the CPU
Remove the CPU according to the following procedures and Figure 4.37.
CAUTION:
When removing the CPU, keep the following in mind:
The CPU can become very hot during operation. Be sure to let it cool down before starting
repair work.
1. Use a flat blade screwdriver to unlock the CPU by rotating the cam on the CPU socket
counterclockwise to the unlock position, aligning the divot on the cam with the
‘unlocked’ icon as shown in Figure 4.37.
2. Remove the CPU.
Figure 4.37 Removing the CPU

Toshiba Satellite A660 Series Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	Wi-Fi 802.11b/g/n
HDMI	Yes
Battery	6-cell Lithium-ion
Processor	Intel Core i5
RAM	4GB or 8GB DDR3
Storage	Up to 640GB HDD
Graphics	NVIDIA GeForce GT 330M
Operating System	Windows 7 Home Premium or Professional
Webcam	Yes, with built-in microphone
Audio	Stereo speakers, Dolby Advanced Audio
LAN	10/100 Ethernet
Card Reader	Multi-Card Reader
USB Ports	3 x USB 2.0
Ports	Microphone input, Headphone output
