Toshiba Satellite A660 Series Maintenance Manual

4 Replacement Procedures 4.18 Thermal Module
Satellite A660/A665/A660D Maintenance Manual 4-44
4.18 Thermal Module
Removing the Thermal Module
Remove the thermal module according to the following procedures and Figures 4.34.
CAUTION:
When removing the thermal module, keep the following in mind:
1.
The unit can become very hot during operation. Be sure to let it cool down before
starting the repair work.
2.
Use care when removing and disassembling the unit in order to avoid damage.
3.
If you remove the thermal module, please use a soft cloth with alcohol to clean it.
Reapply Shinetsu 7762 grease before installing the thermal module. If you use a new
thermal module, please ensure to remove the release paper first.
1. Remove the three M2.5x6.5 spring screws and the four M2.5x6 spring screws in the order
indicated in Figure 4.34.
2. Remove the thermal module.
Figure 4.34 Removing the thermal module
M2.5x6*4
M2.5x6.5*3

Toshiba Satellite A660 Series Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	Wi-Fi 802.11b/g/n
HDMI	Yes
Battery	6-cell Lithium-ion
Processor	Intel Core i5
RAM	4GB or 8GB DDR3
Storage	Up to 640GB HDD
Graphics	NVIDIA GeForce GT 330M
Operating System	Windows 7 Home Premium or Professional
Webcam	Yes, with built-in microphone
Audio	Stereo speakers, Dolby Advanced Audio
LAN	10/100 Ethernet
Card Reader	Multi-Card Reader
USB Ports	3 x USB 2.0
Ports	Microphone input, Headphone output
