Toshiba Satellite A660 Series Maintenance Manual

4.6 TV Tuner Card and WLAN Card 4 Replacement Procedures
Satellite A660/A665/A660D Maintenance Manual 4-21
4.6 TV Tuner Card and WLAN Card
Removing the WLAN Card
Remove the WLAN card according to the following procedures and Figure 4.12.
1. Disconnect the two antennas on the WLAN card.
2. Remove one M2.5x5 screw securing the WLAN card as shown in Figure 4.12.
3. Pull the WLAN card out at an angle.
Figure 4.12 Removing the WLAN Card
Removing the TV Tuner Card
Remove the TV tuner card according to the following procedures and Figure 4.13.
1. Disconnect the antenna on the TV tuner card.
2. Remove one M2.5x5 screw on the TV tuner card as shown in Figure 4.13.
3. Pull the TV tuner card out at an angle.
M2.5x5*1

Toshiba Satellite A660 Series Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	Wi-Fi 802.11b/g/n
HDMI	Yes
Battery	6-cell Lithium-ion
Processor	Intel Core i5
RAM	4GB or 8GB DDR3
Storage	Up to 640GB HDD
Graphics	NVIDIA GeForce GT 330M
Operating System	Windows 7 Home Premium or Professional
Webcam	Yes, with built-in microphone
Audio	Stereo speakers, Dolby Advanced Audio
LAN	10/100 Ethernet
Card Reader	Multi-Card Reader
USB Ports	3 x USB 2.0
Ports	Microphone input, Headphone output
